Our machines
Three ranges, shared construction principles.
VISIO Pro for visual communication, TEKNO for industrial production and PRIMA for your first step towards in-house production. Heavy-duty steelwork and Italian CNC control, with heads, spindles and formats configured for the application.
Range 01 · visual communication
VISIO Pro
Router, knife and creasing wheel on the same head; registration camera. 3200 × 2050 and 4050 × 2050 mm.
Find out more →
Range 02 · industrial production
TEKNO
Aluminium, engineering polymers and solid wood; five formats, materials up to 150 mm thick and automatic tool change, depending on configuration.
Find out more →
Range 03 · your first step towards in-house production
PRIMA
3050 × 2050 mm bed, six-zone vacuum bed, vision system and automatic tool change as standard, 4.5 kW.
Find out more →| Specification | VISIO Pro | TEKNO | PRIMA |
|---|---|---|---|
| Who it is for | Exhibition contractors, printers and sign makers | Industrial SMEs, prototyping and subcontract machining | Advanced craft businesses, joinery workshops, sign makers and print shops |
| Working areas | 3200 × 2050 · 4050 × 2050 mm; materials up to 90 mm thick | 1250 × 1250 · 2050 × 1250 · 1250 × 2600 · 2050 × 3050 · 2050 × 4050 mm; materials up to 150 mm thick | 3050 × 2050 mm; 90 or 150 mm Z travel |
| Spindle | 4.5–9 kW · up to 36,000 rpm | 4.5–9 kW · up to 36,000 rpm | 4.5–9 kW · 24,000 rpm |
| Multi-tool head (knife, creasing wheel) | standard / module | — | — |
| Vision system | yes | — | yes |
| Automatic tool change | module | yes | yes |
Configuration details depend on the selected machine, tools and application. See each machine page for further specifications and confirm the final configuration with Automa.
Material testing
Bring us a file, a material and a target result.
Contact us with your machining file and material details: together we will agree on testing arrangements and availability.
You will speak to someone at Automa. We discuss pricing after understanding your work, rather than sending a standard price by email.
